Unit 07-469 – 400 HP, Sweet, Reciprocating Compressor
Specifications
| Unit Number | 07-469 |
| HP | 400 |
| RMP | 1800 |
| Service | Sweet |
| Stages | 3 |
| Packager | Bidell |
| Driver | Waukesha F18GL |
| Compressor | Ariel JGJ4 |
| Stage 1 | (2) 9.75″ |
| Stage 2 | (1) 6.0″ |
| Stage 3 | (1) 3.625″ |
| Stage 4 | N/A |
| Cooler | AXH 108AEF |
| Control Panel | RemVue 500S |
| Base | Skid |
| Building | Yes |
| Heaters | 12VDC Catadyne |
| Silencer | Hospital Grade |
| Suction MAWP | 655 PSIG |
| Discharge MAWP | 1932 PSIG |
| Crane | No |
Options
| Suction Control Valve | Yes |
| Bypass | Auto |
| Blowdown | Manual |
| Instrument supply | Air |
| Auto louvres (gas) | Yes |
| Cooler Drive | Jackshaft |
| Seal Pot System | No |
| Vacuum Pump System | No |
| Building Electrical | No |
| B149 | Option |
